The Trojan MTVS is a vacuum system with high capacity vacuum pump & blower set for pulling vacuum on transformer main tanks prior to filling.

Operating Capacity

Total Capacity to suit

Able to maintain main tank vacuum of <1 Torr, or as required

Ultimate pressure lower than 10 microns (VP & Booster combined)

Vacuum Pump & Booster / Blower Unit

Various sizes & ultimate pressure options available to suit

Safety Features

Safety alarms with visual indicators - instantly shut down the System.

Vacuum level reduced when foam or liquid detected

Isolation Valves for quick shut off

Construction

All weather canopy

Stainless Steel construction of tanks and pipe work

General Features

Vacuum pressure sensors at main tank & vacuum pump inlet

Main Tank Flushing System to optimize water removal from the windings

Pipe set combination of tubing & flexible hoses

Visual display of vacuum levels

Vacuum Line Oil Tank with baffles & foam level sensor

Freeze Trap for collection of moisture from transformer main tank

Highly portable, small & compact

Support / Warranty

12 month full warranty and ongoing support as required

Service and support

Parts replacement – all key parts from local suppliers
